Trasducer input voltage:	5 V (max 6 load cells 350 Ohm)
Measuring range:	-1.5 ÷ +3.5 mV/V
Input sensitivity:	0.02 µV/ per count
Linearity:	±0.01% of R.O.
Thermic drift:	±0.001% R.O./°C
Display:	Alphanumeric backlit LCD, 2 lines and 16 scripts
A/D Converter:	24 bit
Internal resolution:	> 16.000.000 counts
Visible resolution:	600.000 divisions
Divisions value (adjustable):	x1, x2, x5
Set decimal:	0.0 ; 0.00 ; 0.000
Filter:	0.1 ÷ 25 Hz adjustable
Keyboard:	4 membrane keys
Tool voltage:	24 Vcc ±15% - 12 W
Temperature range:	-10 ÷ +50°C
Storage temperature:	-20 ÷ +70°C
Logic output:	2 relays (NA) - 115 V ca/30 V cc , 0.5 A
Logic input:	2 optoisolated 24 V cc PNP
Serial door:	COM1: RS232 COM2: RS422/RS485
Transmission distance:	15m (RS232C), 1000m (RS422 and RS485)
FIELDBUS protocol:	PROFIBUS, DEVICENET, ETHERNET (opzionals)
Protocol:	ASCII, Modbus RTU
Baud rate:	1200 ÷ 115200 adjustable
Analog optional output:	16 Bit optoisolated - Tension: 0÷5/10V (R min10 K Ohm) Current: 0/4÷20mA (R max 300 Ohm)
Regulatory compliance:	EN61000, EN61000 for EMC; EN61010-1 for electrical safety
Electrical connection:	Screw terminals 5 mm
Dimensions:   型號： dat 400 dat 450 dat-s 400 dat 500 lc 100 mc  102 mcs 102 mc 302 mc s 302 uwt 600 uwt 600i i box 20004   更多稱重傳感器推薦 稱重傳感器，壓力傳感器，加速度感器，加速度傳感器，扭矩傳感器	100 x 75 x 110 mm (L x H x D)
